electric butterfly valve?
electric butterfly valve?
electric butterfly valve?
pneumatic butterfly valve

butterfly valve with actuator?

Body: DI,WCB,CF8,CF8M,CF3M
Disc: SS304,SS316,SS316L
Seats: NBR,EPDM,VITON,FKM,PTFE
Body stlye:? Wafer,Lug,Flanged
Stem: Stainless Steel
Size: 2″ – 60″ (50mm – 1500mm)
End: PN10,PN16,5K,10K,16K,150LB
Electric actuator:?ON-OFF type、Regulation type
Power:?12 VDC,24 VAC,24 VDC,220 VAC,120 VAC,380 VAC 50/60 Hz ±10%







    Description

    Butterfly valve with electric actuator. Designed with a robust body of ductile iron, WCB, or stainless steel, this electric actuated butterfly valve offers versatility and durability. Available in wafer and lug styles, it features disc options like SS304, SS316, SS316L, and super duplex steel, paired with NBR, EPDM, VITON, or PTFE seats. With connections including wafer, lug, and flanged, a size range of 2”~60” (DN50-DN1500), and pressure ratings up to PN16 and 150lb, this electric butterfly valve suits various industrial needs. Equipped with ON-OFF or Regulation type 4-20mA electric actuators, these actuated butterfly valves deliver precision for handling gas, water, and oil efficiently.

    Body Ductile iron,WCB, stainless steel
    Body stlye Wafer,Lug
    Disc SS304,SS316,SS316L,Super duplex steel
    Seat NBR,EPDM,VITON,PTFE
    Connection wafer,lug,flanged
    Size 2”~60” DN50-DN1500
    Pressure PN10 PN16 5k 10k 150lb
    Medium Gas, Water and Oil, etc
    Electric Actuator ON-OFF type、Regulation type 4-20mA
    Voltage 12 VDC,24 VAC,24 VDC,220 VAC,120 VAC,380 VAC 50/60 Hz ±10%

    electric actuated butterfly valve?

    FAQ

    What should be considered when selecting a butterfly valve with an actuator?

    Key factors include the operating medium, system pressure, temperature requirements, valve size, and actuator type (ON-OFF or modulating). Ensuring compatibility with the body, disc, and seat materials is crucial for optimum performance.

    How should I install a butterfly valve with an actuator?

    Begin by aligning the valve between the flanges, ensuring the disc does not interfere with the pipe. Secure bolts diagonally to prevent

    misalignment. Once installed, connect the actuator, ensuring the power source or signal wiring is properly configured. Test operation before system integration.

    Are butterfly valves with actuators suitable for corrosive or high-temperature environments?

    Yes, selecting the appropriate materials ensures compatibility with specific conditions. For example, stainless steel discs and PTFE seats can handle corrosive substances, while VITON seats are ideal for high-temperature applications.

    What sizes and pressure ratings are available for butterfly valves with actuators?

    These valves are available in sizes ranging from 2” to 60” (DN50 to DN1500) and can handle pressure ranges up to PN16, 150lb, and beyond, making them versatile for both low- and high-pressure systems.
